470W LED Spot / Wash
LED | CMY | FRAMING SHUTTER

470W LED Spot/Wash is the latest Spot / Wash moving head with all the functions that you need. Build with 470W LED light engine it offers an practical & even projection. Colors enriched by 7 color wheels with CMY color mixing system, and CTO with 3200-6000K for more color creations. Equipped with 4-way framing shutter with rotating effects, the 470W LED Spot/Wash offers the possibility to create more unique shape of light projection.

Features
  • 470W LED Light Engine

  • Beam Angle: 8°-53°

  • Framing Shutter + Rotation + Iris

  • CMY color mixing + Color wheels + CTO

  • Smooth Pan/Tilt movement



  • 470W LED Light Engine

  • Beam Angle: 8°-53°

  • Static Gobo: 8 gobo + open

  • Rotation Gobo: 6 gobo + open, changeable

  • 4 Facet Prism

  • 7 color wheels +CMY color mixing+CTO (3200-6000K)

  • Frost

  • Iris + Framing Shutter system, rotatable.

  • 0-100% Linear Dimmer with Electronic shutter

  • Input: Auto switching 100-240V AC, 50/60 Hz

  • Max power consumption: 800W

PHYSICAL DIMENSIONS/ WEIGHT:

  • Height (Head in vertical position): 847 mm

  • Width: 482 mm

  • Depth: 371 mm

  • Weight: 40.5 kg
